Figure41
Driveaxelatengine,ve,oneeachsideandslipjoint
1.Greasepoint
Figure42
Driveaxelattransmission
1.Greasepoint
Figure43
Steeringpivotabovesteeringrods
1.Greasepoint
GreasingtheBoomHinges
ServiceInterval:Every100hours
Important:Iftheboomhingeiswashedwith
water,allwateranddebrismustbeclearedfromthe
hingeassemblyandfreshgreasemustbeapplied.
GreaseType:No.2general-purposelithiumbase
grease.
1.Wipethegreasettingscleansothatforeignmatter
cannotbeforcedintothebearingorbushing.
2.Pumpgreaseintothebearingorbushingateach
tting
Figure44.
Figure44
Rightboom
1.Greasetting
3.Wipeoffexcessgrease.
4.Repeattheprocedureforeachboompivot.
GreasingtheActuatorRod
Bearings
ServiceInterval:Every400hours/Yearly(whichever
comesrst)
GreaseType:No.2general-purposelithiumbase
grease.
1.Extendtheboomstothesprayposition.
2.Removethecotterpinfromthepivotpin(Figure45).
42
