Toopenthefreshwatertankspigot,turntheleveron
thespigot.
Figure24
1.Freshwatertank
3.Spigot
2.Fillercap
FillingtheSprayTank
Important:Ensurethatthechemicalsyouwill
beusingarecompatibleforusewithViton(see
themanufacturer’slabel;itshouldindicateifit
isnotcompatible).Usingachemicalthatisnot
compatiblewithVitonwilldegradetheO-ringsin
thesprayer,causingleaks.
Important:Verifythattheproperapplicationrate
hasbeensetpriortollingthetankwithchemicals.
1.Stopthesprayeronalevelsurface,movetherange
selectortotheNeutralposition,stoptheengine,
andsettheparkingbrake.
2.Ensurethatthetankdrainvalveisclosed.
3.Determinetheamountofwaterneededtomixthe
amountofchemicalyouneedasprescribedbythe
chemicalmanufacturer.
4.Openthetankcoveronthespraytank.
Thetankcoverislocatedinthecenterofthetopof
thetank(
Figure25).Toopenit,turnthefronthalf
ofthecovercounterclockwiseandswingitopen.
Youcanremovethestrainerinsideforcleaning.To
sealthetank,closethecoverandrotatethefront
halfclockwise.
G001897
1
2
Figure25
1.Tankcover
2.Anti-siphonllreceptacle
5.Add3/4oftherequiredwatertothespraytank
usingtheanti-siphonllreceptacle.
Important:Alwaysusefreshcleanwaterin
thespraytank.Donotpourconcentrateinto
anemptytank.
6.SetthepumpswitchtotheOnposition.
7.Starttheengine,presstheacceleratorpedaltothe
oor,andsettheneutralenginespeedlocktothe
Onposition.
8.SetthemasterboomswitchtotheOffposition.
TheSprayPromonitorwilldisplay“HOLD”.
9.Turntheagitationcontrolvalvetothe9o’clock
positiontostartagitationinthetank.
10.Addtheproperamountofchemicalconcentrateto
thetank,asdirectedbythechemicalmanufacturer.
Important:Ifyouareusingawettablepowder,
mixthepowderwithasmallamountofwaterto
formaslurrybeforeaddingittothetank
11.Addtheremainingwatertothetank.
OperatingtheBooms
Theboomliftswitchesonthesprayercontrolpanel
allowsyoutomovetheboomsbetweentransport
positionandspraypositionwithoutleavingthe
Operator’sseat.Itisrecommendedtochangeboom
positionswhilethemachineisstationary.
Tochangetheboomposition:
1.Stopthesprayeronlevelground.
29
