Figure31
1.Pump3.Pressuredampener
2.Greasetting
AdjustingtheAirPressurein
Dampener
Theairpressureinthedampeneronthepumpissetat
15psi(1bar)bythemanufacturer.Therecommended
pressureinthedampeneris1/3ofthespraying
pressure.Ifusingaspraypressuregreaterthan45psi
(3.1bar)adjustthedampeneraccordingly.
G010597
Figure32
TransportingtheSprayer
Formovingthesprayerlongdistances,useatrailer.
Securethesprayertothetrailer.Figure33illustrates
thefronttie-downpoints.
Figure33
1.Tiedownpoints
Thereartie-downpointsaretwosteelloopsunderthe
backoftheframejustinfrontoftheadjustableboom
frame.
TowingtheSprayer
Incaseofanemergency,thesprayercanbetowedfor
ashortdistance.However,wedonotrecommendthis
asastandardprocedure.
WARNING
Towingatexcessivespeedscouldcausealossof
steeringcontrol,resultinginpersonalinjury.
Nevertowthesprayerfasterthan5mph(8kph).
Towingthesprayerisatwopersonjob.Ifthemachine
mustbemovedaconsiderabledistance,transportiton
atruckortrailer;refertoTransportingtheSprayer.
1.Afxatowlinetotheframe.
2.PuttherangeselectorintheNeutralpositionand
releasetheparkingbrake.
3.Towthesprayeratlessthan5mph(8kph).
36
