fromthemachineandpourthefueloutofthetank
llspoutintothefuelcontainer.
Note:Ifyouremovethefueltank,youwillneed
toremovethefuelandreturnhosesfromthetank
beforeremovingthetank.
2.Replacethefuellter;refertotheReplacingtheFuel
Filtersection.
3.Flushthetankwithfresh,cleanfuel,ifnecessary.
4.Installthetankifyouremoveditinstep1.
5.Fillthetankwithfresh,cleanfuel.
ElectricalSystem
Maintenance
Fuses
Thereare2fuseblocksand1emptyslotintheelectrical
system.Theyarelocatedbeneaththeseat(Figure56).
Figure56
1.Leftboomactuatorthermal
breaker
6.Headlights
2.Rightboomactuator
thermalbreaker
7.Cruisecontrol
3.Foammarker
8.Spraysystem
4.Openslot
9.Fuseblocks
5.Power
ServicingtheBattery
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
Important:Donotjumpstartthesprayer.
Alwayskeepthebatterycleanandfullycharged.Use
apapertoweltocleanthebatteryandbatterybox.If
thebatteryterminalsarecorroded,cleanthemwitha
solutionoffourpartswaterandonepartbakingsoda.
Applyalightcoatingofgreasetothebatteryterminals
topreventcorrosion.
Voltage:12voltwith280coldcrankingAmps@0
degreesF
48
