BeltMaintenance
ServicingtheDriveBelt
CheckingtheDriveBelt
ServiceInterval:Aftertherst8hours
Every200hours
1.Positionthesprayeronalevelsurface,setthe
parkingbrake,movetherangeselectortotheNeutral
position,stopthepump,stoptheengine,andremove
theignitionkey.
2.Rotateandinspectthedrivebeltforexcessivewear
ordamage.Replacethebeltifnecessary.
Figure63
1.Drivebelt
3.Secondaryclutch
2.Primaryclutch
ReplacingtheDriveBelt
1.Rotateandroutethebeltoverthesecondaryclutch
(Figure63).
2.Removethebeltfromtheprimaryclutch.
3.Placethenewbeltovertheprimaryclutch.
4.Rotateandinstallitoverthesecondaryclutch.
AdjustingtheSteeringPump
Belt
ServiceInterval:Aftertherst8hours
Every100hours
Thebeltshouldex1/4inch(5mm)when5lbofforce
(22N)isappliedmidwayonthetopspan.
1.Parkthemachineonalevelsurface,settheparking
brake,turntheignitionoff,andremovethekey.
2.Loosenthesteeringpumpmountingbolts
(Figure64).
Figure64
1.Steeringpumpbelt3.Steeringpumpmounting
bolts
2.Steeringpump
3.Movethepumpuntilthebeltexes1/4inch(5mm)
with5lb.offorce(22N)thentightenthemounting
bolts,startingwiththeboltclosesttotheengine
crankshaft.
53
