Figure66
1.Belt
3.Spring
2.Spring-loadedidlerpulley
ReplacingthePump-DriveBelt
ServiceInterval:Every100hours—Checkthepump-drive
belt.
1.DisengagethePTOandsettheparkingbrake.
2.Shutofftheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Removethemower-deckbelt.
4.Tiltthemachine;refertoRaisingtheMowerforAccess
(page30).
5.Removetheshoulderbolt,thenut,andthewasher
fromtheenginedeckandconnectedspring(Figure67).
G015402
1
2
3
5
4
6
Figure67
1.Hydraulicpumps
4.Clutchretainer
2.Idlerpulley5.Pump-drivebelt
3.Clutchpulley6.Shoulderbolt,nut,and
washer
6.Removethepump-drivebelt(Figure67).
7.Installthenewbeltaroundtheclutchandthe2pump
pulleys.
8.Installthespringontotheshoulderboltandwasher,
andconnectittotheenginedeckwiththenut(Figure
67).
9.Lowerthemachinetotheoperatingposition.
10.Installthemower-deckbelt.
