Parking Brake Lever
T o set the parking brak e , push the brak e lev er
forw ard and to the left and then pull it rearw ard
( Figure 8 ).
Note: T he traction unit ma y roll slightly before
the brak es eng ag e in the dri v e sproc k et.
Figure 8
T o release the brak e , push the lev er forw ard and
then right, into the notc h.
Fuel Gauge
T his g aug e measures the amount of fuel in the fuel
tank.
Hydraulic Oil Temperature Light
(Dingo TX 425 only)
If the h y draulic oil g ets too hot, this light
illuminates and an audible alar m sounds . If this
happens , stop the engine and allo w the traction
unit to cool.
Hour Meter/Tachometer
W hen the engine is off , the hour meter/tac hometer
displa ys the n umber of hours of operation that
ha v e been log g ed on the traction unit. W hen the
engine is r unning, it displa ys the speed of the
engine in rev olutions per min ute (r pm).
After 50 hours and then ev er y 100 hours thereafter
(that is at 150, 250, 350, etc .) the screen displa ys
CHG OIL to remind y ou to c hang e the engine oil.
After ev er y 100 hours , the screen displa ys SV C
to remind y ou to perfor m the other maintenance
procedures based on a 100, 200, or 400 hour
sc hedule . T hese reminders come on star ting three
hours prior to the ser vice inter v al time and flash
at regular inter v als for six hours .
