Toro TimeCutter SW5425 User Manual

SPECIFICATIONS
2-1
Toro TimeCutter SW/SWX Service Manual
2
2015 TimeCutter Zero Turn Tractor Specications
Conguration SW3200 SW4200 SW5000
16 HP 452cc Toro 32” Mower, 1 Blade
22 HP 725 cc Kohler 42” Mower, 2 Blades
24.5 HP 708cc Toro 42” Mower, 2 Blades 42” Mower, 2 Blades
Power Systems
Clutch Electric Electric Electric
Transaxles Twin Hydro-Gear ZT-2100 Twin Hydro-Gear ZT-2100 Twin Hydro-Gear ZT-2200
Drive Belt Drive with self-
tensioning system
Belt Drive with self-
tensioning system
Belt Drive with self-
tensioning system
Max. Ground Speed
(Fwd)
(Rev)
High 7.0 MPH
Low 4.0 MPH
3.5 MPH
High 7.0 MPH
Low 4.0 MPH
3.5 MPH
High 7.0 MPH
Low 4.0 MPH
3.5 MPH
Rear Tires 18 x 6.0-8 2-ply rated 18 x 7.5-8 2-ply rated 18 x 7.5-8 2-ply rated
Front Caster Tires 11 x 4.00-5 ribbed tread,
2-ply rated
13 x 5.00-6 ribbed tread,
2-ply rated
13 x 5.00-6 ribbed tread,
2-ply rated
Fuel Tank Capacity 3 gallons 3 gallons 3 gallons
Mowing Deck
Type Side Discharge Side Discharge Side Discharge
Deck Construction/
Material
13 gauge steel 13 gauge steel 12 gauge steel
Spindle Housing Die cast aluminum Die cast aluminum Die cast aluminum
Spindle Shaft/Bearings One 19.9mm diameter
spindle/permanently lubed
ball bearings
Two 17mm diameter
spindles/permanently
lubed ball bearings
Three 17mm diameter
spindles/permanently
lubed ball bearings
Blade Tip Speed 18,959 ft/min @ 3400
RPM
17,810 ft/min @ 3400
RPM
18,330 ft/min @ 3400
RPM
Cutting Height Positions 1.5” to 4.5” 7 positions 1.5” to 4.5” 7 positions 1.5” to 4.5” 7 positions
Anti-Scalp Rollers None 2 adjustable 2 adjustable
Frame Construction Riveted 10 gauge steel Riveted 10 gauge steel Riveted 10 gauge steel
Dimensions
Weight 554 lbs. 595 lbs. 659 lbs.
Width Outside Rear Tires 34.6” (87.9cm) 38.6” (99cm) 46.2” (117.3cm)
Width Outside Deck 39.2” (99.4cm) Deck
deector down
36.2” (91.9cm) Deck
deector up
53.8” (136.6cm) Deck
deector down
46.1” (117cm) Deck
deector up
63.1” (160.3cm) Deck
deector down
55” (139.7cm) Deck
deector up
Wheel Base 50.5” (128.3cm) 50.5” (128.3cm) 50.5” (128.3cm)
Overall Length 78.9” (200cm) 78.9” (200cm) 78.9” (200cm)
Height 45.4” (115.3cm) 45.4” (115.3cm) 45.4” (115.3cm)

Toro TimeCutter SW5425 Specifications

General

Brand	Toro
Model	TimeCutter SW5425
Category	Lawn Mower
Language	English
