SPECIFICATIONS
2-6
Toro TITAN 2009-2013 Service Manual
2
2011 - 2013 TITAN ZX & MX Specications cont.
Congurations TITAN MX4880 TITAN MX5480 TITAN MX6080
21.5 HP Kawasaki V-Twin 48” SD, 3-Blades
23 HP Kawasaki V-Twin 54” SD, 3-Blades
24 HP Kawasaki V-Twin 60” SD, 3-Blades
Power Systems TITAN MX4880 TITAN MX5480 TITAN MX6080
Clutch Electric Electric Electric
Transaxles Twin Hydro-Gear ZT-3100
with Charge Pump,
Shock Valves and
Heavy Duty Gears
Twin Hydro-Gear ZT-3100
with Charge Pump,
Shock Valves and
Heavy Duty Gears
Twin Hydro-Gear ZT-3100
with Charge Pump,
Shock Valves and
Heavy Duty Gears
Drive Belt Drive self-tensioning
system
Belt Drive self-tensioning
system
Belt Drive self-tensioning
system
Maximum Ground Speed 7.5 mph/3.8 mph 7.5 mph/3.8 mph 7.5 mph/3.8 mph
Rear Drive Tires 22”X10”-10 4 ply rated 22”X10”-10 4 ply rated 22”X10”-10 4 ply rated
Front Caster Tires 12”X6”-6 Smooth Tread 12”X6”-6 Smooth Tread 12”X6”-6 Smooth Tread
Fuel / Capacity 5 gallons (18.9 L) 5 gallons (18.9L) 5 gallons (18.9L)
Mower Decks TITAN MX4880 TITAN MX5480 TITAN MX6080
Type Side Discharge Side Discharge Side Discharge
Deck Construction
Material
10 gauge fabricated steel 10 gauge fabricated steel 10 gauge fabricated steel
Spindle Housing Die cast aluminum Die cast aluminum Die cast aluminum
Spindle Shaft/Bearings Three 25mm diameter
spindles in permanently
lubed ball bearings
Three 25mm diameter
spindles in permanently
lubed ball bearings
Three 25mm diameter
spindles in permanently
lubed ball bearings
Blade Tip Speed 18,800 ft/min @
3700 RPM
18,644 ft/min @
3700 RPM
18,908 ft/min @
3700 RPM
Cutting Height 1.5” to 4.5” 13 Positions 1.5” to 4.5” 13 Positions 1.5” to 4.5” 13 Positions
Anti-Scalp Rollers 3 Adjustable 3 Adjustable 3 Adjustable
Frame Construction 1.5” X 3” (.109” wall)
Mechanical Steel Tubing
1.5” X 3” (.109” wall)
Mechanical Steel Tubing
1.5” X 3” (.109” wall)
Mechanical Steel Tubing
Dimensions TITAN MX4880 TITAN MX5480 TITAN MX6080
Weight 797 lbs. (estimated) 813 lbs. (estimated)
Width Outside Tires 47.2” (119.9cm) 47.2” (119.9cm) 47.2” (119.9cm)
Width Outside Deck 61.5” Deector Down
52.4” Deector Up
67.9” Deector Down
57.7” Deector Up
75.0” Deector Down
63.0” Deector Up
Wheel Base 49.2” (125.0cm) 49.2” (125.0cm) 49.2” (125.0cm)
Overall Length 77.4” (196.6cm) 77.4” (196.6cm) 77.4” (196.6cm)
Overall Height 73.4” ROPS Up
46.9” ROPS Down
73.4” ROPS Up
46.9” ROPS Down
73.4” ROPS Up
46.9” ROPS Down
