134
Specifications
Acceptable signal formats for HDMI®
Acceptable signal formats for HDMI
®
HDMI
®
signal formats
Format Resolution V. Frequency H. Frequency Pixel Clock
Frequency
VGA 640 x 480 59.940 Hz 31.469 kHz 25.175 MHz
SVGA 800 x 600 60.317 Hz 37.879 kHz 40.000 MHz
XGA 1024 x 768 60.004 Hz 48.363 kHz 65.000 MHz
WXGA
1280 x 768 59.870 Hz 47.776 kHz 79.500 MHz
1360 x 768 60.015 Hz 47.712 kHz 85.500 MHz
SXGA 1280 x 1024 60.020 Hz 63.981 kHz 108.000 MHz
480i 720 x 480i 59.940 Hz 15.734 kHz 27.000 MHz
480p 720 x 480p 59.940 Hz 31.469 kHz 27.000 MHz
720p 1280 x 720p 60.000 Hz 45.000 kHz 74.250 MHz
1080i 1920 x 1080i 60.000 Hz 33.750 kHz 74.250 MHz
1080p 1920 x 1080p
24.000 Hz 27.000 kHz 74.250 MHz
60.000 Hz 67.500 kHz 148.500 MHz
v Some illustrations in this User’s Guide are for explanation purposes
and may differ from the actual unit.
v Designs and specifications are subject to change without notice.
v These models may not be compatible with features and/or
specifications that may be added in the future.
