- 95 -
5. Addition/Deletion of Standard TCP/IP Port
When connecting the printer via LAN interface, configure the following settings on the printer using the printer
system mode menu <7>IP ADDRESS.
• PRINTER IP ADDRESS
• GATEWAY IP ADDRESS
• SUBNET MASK
• SOCKET PORT
The above PRINTER IP ADDRESS and SOCKET PORT are used as the “Printer Name or IP address” and “Port
No.”, respectively when adding a port.
Note: When the “Bi-directional support” is used, do not specify the same output port for the multiple printer drivers on a
computer. When you want to specify the same output port for the multiple printer drivers, disable the [Printer Status
Monitoring].
Also, when multiple computers connect to the same printer, specify that printer as the shared printer or disable the
[Printer Status Monitoring].
To Next Page
