8-8. Leakage/Clogging of Refrigerating Cycle Circuit

List of Check Codes Generated upon Occurrence of Leakage/Clogging in Outdoor Cycle

or Oil Circuit Part

(MMY-MAP0804#, 1004#, 1204#)

Clogging

Leakage

Note: “XX” represents sub-code

Part

Site of fault

(see next page)

Unit generating

check code

Detected fault and check code Symptom

Outdoor PMV1, 2

Corresponding unit Activation of high-pressure protection

Activation of low-pressure protection

Discharge temp. error (TD1)

Discharge temp. error (TD2)

P20

H06

P03

P17

Rise of pressure

Fall of pressure

Rise of discharge temp.

(compressor 1)

Rise of discharge temp.

(compressor 2)

Check valve in discharge pipe

convergent section

Corresponding unit High-pressure protection error

High-pressure SW system error

P20

P04-XX

Abnormal rise of pressure

Check valve in discharge pipe C Corresponding unit High-pressure SW system error P04-XX Abnormal rise of pressure

Check valve in oil-equalization circuit

Capillary

Strainer

Corresponding unit Oil level detection circuit error

Oil level low detection and protection

H16-XX

H07

Oil circuit error or oil level low

SV3A valve E Other connected unit Oil level low detection and protection H07 Oil level low

SV3B valve F Corresponding unit Oil level low detection and protection H07 Oil level low

SV3C valve G Other connected unit Oil level low detection and protection H07 Oil level low

SV3D valve

SV3D valve circuit capillary

Strainer

Corresponding unit Oil level low detection and protection H07 Oil level low

SV3E valve

Corresponding unit Oil level detection circuit error

Oil level low detection and protection

H16-05

H07

Oil circuit error

Oil level low

Oil return distributor J Corresponding unit Oil level low detection and protection H07 Oil level low

SV3C bypass capillary K Corresponding unit Oil level detection circuit error H16-04 Oil circuit error

Part

Site of fault

(see next page)

Unit generating

check code

Detected fault and check code Symptom

Outdoor PMV1, 2

Corresponding unit Outdoor liquid backflow error

Oil level low detection and protection

P13

H07

Refrigerant entrapment

Other connected unit Discharge temp. error (TD1)

Discharge temp. error (TD2)

P03

P17

Rise of discharge temp.

(compressor 1)

Rise of discharge temp.

(compressor 2)

Check valve in discharge pipe

convergent section B

Corresponding unit Oil level low detection and protection

Compressor breakdown

Compressor error (lockup)

H07

H01-XX

H02-XX

Refrigerant entrapment

Check valve in discharge pipe

Corresponding unit Oil level low detection and protection

Compressor breakdown

Compressor error (lockup)

H07

H01-XX

H02-XX

Refrigerant entrapment

Check valve in oil-equalization circuit

Corresponding unit Oil level low detection and protection H07 Excessive amount of oil

(Leaking side)

Insufficient amount of oil

(Normal side)

SV3A valve E Corresponding unit Oil level low detection and protection H07 Oil level low

SV3C valve G Corresponding unit Oil level low detection and protection H07 Oil level low
