Parts Rating
2-1. Outdoor Unit (50Hz model: MMY-MAP 4HT8-E,
MAP 4HT8-TR, MAP 4HT8, MAP 4T8-SG)
Name Model Specification
MMY-MAP0804
MMY-MAP1004
MMY-MAP1204
MMY-MAP1404
MMY-MAP1604
1 Compressor DA421A3FB-29M Output: 2.3kW×2 O
1 Compressor DA421A3FB-29M Output: 3.1kW×2 O
1 Compressor DA421A3FB-29M Output: 4.2kW×2 O
1 Compressor DA421A3FB-29M Output: 3.0kW×3 O
1 Compressor DA421A3FB-29M Output: 3.6kW×3 O
2 4-way valve coil STF AC220-240V 50Hz O O O O O
3 Pulse motor valve coil HAM-MD12TF-6 DC12V O O O O O
4
2-way valve coil VPV AC220-240V 50Hz
SV2,SV3A,SV3B,SV3C,SV3D,SV3E
O O O
AC220-240V 50Hz
SV2,SV3A,SV3B,SV3C,SV3D,SV3E,SV3F,SV6
O O
5
2-way valve coil FQ-G593 AC220-240V 50Hz
SV41,SV42,SV5
O O O
AC220-240V 50Hz
SV41,SV42,SV43
O O
6 High-pressure SW ACB-4UB32W OFF:3.73MPa ON:2.9MPa O O O O O
7 Pressure sensor (For high pressure) NSK-BC038F-067 0.5~4.3V/0~3.73MPa O O O O O
8 Pressure sensor (For low pressure) NSK-BC010F-067 0.5~3.5V/0~0.98MPa O O O O O
9 Fan motor STF-340A1000-1 DC280V/1kW O O O O O
10 Case heater (For comp.) AC240V/29W O O O O O
11 Case heater (For accum.) AC240V/55W O O O O O
12 Fusible plug 73°C O O O O O
