46
2-4. Outdoor Inverter (60Hz model: MMY-MAP 4HT7)
Name Model Specification
MMY-MAP0804
MMY-MAP1004
MMY-MAP1204
MMY-MAP1404
MMY-MAP1604
1 Power supply terminal block JXO-6004 AC600V/75A,4P O O O O O
2 Relay terminal block for reactor JXO-6B AC250V/20A,6P O O
3 Communication terminal block JXO-B2H AC30V (or no more than DC42V) / 1A, 6P O O O O O
4 Reactor (For comp.) CH-79 5.8mH/16A O O O O O
5 Reactor (For fan) CH-55 5.8mH/14A O O O O O
6 P.C. board (Noise filter) MCC-1608 — O O O O O
7 Line filter — 2.71mH/AC400V/35A O O O O O
8 P.C. board (I/F board) MCC-1606 — O O O O O
9 P.C. board (IPDU for Comp.) MCC-1596 — O O O O O
10 Fuse (MCC-1596) GAC1 31.5A 31.5A/AC500V (P.C. Board) O O O O O
11
Comp. motor drive IPM (MCC-1596) MCC-1596
PS22A76
25A/DC1200V (P.C. Board)
O O O O O
12 P.C. Board (IPDU for fan) MCC-1610 — O O O O O
13 Fuse (MCC-1610) GDT250V15A 15A/AC250V O O O O O
14 Fan motor drive IPM (MCC-1610) FSBB20CH60C 20A/DC600V O O O O O
15 Magnet switch (60Hz) FC-1S AC200-220V O O O O O
16
PTC thermistor MZ32-
101RMARD01E
13A/AC500V
O O O O O
17 Pipe temp. sensor (TD) — -30°C–135°C (Ambient temp. range) O O O O O
18 Pipe temp. sensor (TS) — -20°C–80°C (Ambient temp. range) O O O O O
19 Heat exchanger temp. sensor (TE) — -20°C–80°C (Ambient temp. range) O O O O O
20 Outside temp. sensor (TO) — -20°C–80°C (Ambient temp. range) O O O O O
21 Oil temp. sensor (TK) — -30°C–135°C (Ambient temp. range) O O O O O
22 Liquid temp. sensor (TL) — -20°C–80°C (Ambient temp. range) O O O O O
To Next Page
