2-5. Indoor Unit
4-way Air Discharge Cassette Type
Compact 4-way Air Discharge Cassette Type
Model MMU-AP 0092H 0122H 0152H 0182H 0242H 0272H 0302H
Fan motor SWF-230-60-2R
Motor for horizontal grille MP24ZN3N
Pulse motor EDM-MD12TF-3
Pulse motor valve EDM-B25YGTF-3 EDM-B40YGTF-2
TA sensor Lead wire length: 310mm Vinyl tube
TC1 sensor Ø4 size lead wire length: 1200mm Vinyl tube (Blue)
TC2 sensor Ø6 size lead wire length: 1000mm Vinyl tube (Black)
TCJ sensor Ø6 size lead wire length: 1000mm Vinyl tube (Red)
Float switch FS-0218-102
Drain pump motor MDP-1401
Model MMU-AP 0362H 0482H 0562H
Fan motor ICF-280-150-1
Motor for horizontal grille MP24ZN3N
Pulse motor EDM-MD12TF-3
Pulse motor valve EDM-B60YGTF-1
TA sensor Lead wire length: 310mm Vinyl tube
TC1 sensor Ø4 size lead wire length: 1200mm Vinyl tube (Blue)
TC2 sensor Ø6 size lead wire length: 1000mm Vinyl tube (Black)
TCJ sensor Ø6 size lead wire length: 1000mm Vinyl tube (Red)
Float switch FS-0218-103
Drain pump motor MDP-1401
Model MMU-AP 0071MH 0091MH 0121MH 0151MH 0181MH
Fan motor SWF-230-60-1R
Motor for horizontal grille MP24Z3N
Pulse motor EDM-MD12TF-3
Pulse motor valve EDM-B25YGTF-3 EDM-B40YGTF-3
TA sensor Lead wire length: 155mm Vinyl tube
TC1 sensor Ø4 size lead wire length: 1400mm Vinyl tube
TC2 sensor Ø6 size lead wire length: 1500mm Vinyl tube (Black)
TCJ sensor Ø6 size lead wire length: 1400mm Vinyl tube (Red)
Float switch FS-0218-103
Drain pump motor ADP-1409
