Appendix C Pin Assignments Appendices
TECRA M10 Maintenance Manual (960-685) [CONFIDENTIAL] C-1
Appendix C Pin Assignments
System board (FG6IN*/FGGIN*/FGAIN*)
C.1 CN1400 Memory A connector(200-pin)
Table C-1 Memory A connector (200-pin) (1/3)
Pin No. Signal Name Pin No. Signal Name
1 MRVREF-B0V 2 GND
3 GND 4 ADQ05-B1P
5 ADQ00-B1P 6 ADQ01-B1P
7 ADQ04-B1P 8 GND
9 GND 10 ADM0-B1P
11 ADQS0-B1N 12 GND
13 ADQS0-B1P 14 ADQ02-B1P
15 GND 16 ADQ03-B1P
17 ADQ07-B1P 18 GND
19 ADQ06-B1P 20 ADQ09-B1P
21 GND 22 ADQ08-B1P
23 ADQ12-B1P 24 GND
25 ADQ13-B1P 26 ADM1-B1P
27 GND 28 GND
29
ADQS1-B1N
30
XMCK0-B1P
31 ADQS1-B1P 32 XMCK0-B1N
33 GND 34 GND
35 ADQ15-B1P 36 ADQ11-B1P
37 ADQ14-B1P 38 ADQ10-B1P
39 GND 40 GND
41 GND 42 GND
43 ADQ20-B1P 44 ADQ21-B1P
45 ADQ16-B1P 46 ADQ17-B1P
47 GND 48 GND
49 ADQS2-B1N 50 TSDIMA-P3N
51 ADQS2-B1P 52 ADM2-B1P
53 GND 54 GND
55 ADQ18-B1P 56 ADQ19-B1P
57 ADQ23-B1P 58 ADQ22-B1P
59 GND 60 GND

Toshiba Tecra M10 Specifications

General

Tjunction	100 °C
Processor cache	2 MB
Processor cores	2
Processor model	T6570
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor socket	Socket 478
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.1 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel® GM45 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD
Display diagonal	14.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	4 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Discrete graphics card model	Intel® GMA 4500MHD
Maximum graphics card memory	- GB
Type	PC
Modem speed	56 Kbit/s
Power supply type	AC
Power requirements	100-240V, 50/60Hz
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
DVD+R read speed	8 x
DVD-RAM read speed	5 x
DVD+R Double Layer read speed	6 x
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows Vista Business
Sustainability certificates	ENERGY STAR
Battery capacity	5100 mAh
Number of battery cells	6
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
Product color	Silver
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
AC adapter power	75 W
AC adapter output current	5 A
AC adapter output voltage	15 V
Pointing device	Touchpad
Processor ARK ID	42841

Weight and Dimensions

Depth	245 mm
Width	336.8 mm
Weight	2440 g
Height (rear)	38.4 mm
Height (front)	36.4 mm
