Appendices Appendix C Pin Assignments
C-14 [CONFIDENTIAL] TECRA M10 Maintenance Manual (960-685)
C.9 CN2600 PCI-E Mini CARD interface connector (52-pin)
Table C-9 PCI-E Mini CARD interface connector (52-pin)
Pin No. Signal Name Pin No. Signal Name
1 PEWAKE-E3N 2 E3V
3 WCHDAT-P3P 4 GND
5 WCHCLK-P3P 6 P1V
7 WLXRQ-P3N 8 NC
9 GND 10 NC
11 XPEWL-P0N 12 NC
13 XPEWL-P0P 14 NC
15 GND 16 NC
17 NC 18 GND
19 NC 20 WLRFON-S3N
21 GND 22 PLTRS0-E3N
23 ZERWL-P1N 24 E3V
25 ZERWL-P1P 26 GND
27 GND 28 P1V
29 GND 30 NC
31 ZETWL-P1N 32 NC
33 ZETWL-P1P 34 GND
35 GND 36 ZUSBWM-E3N
37 GND 38 ZUSBWM-E3P
39 E3V 40 WLDET-P3N
41 E3V 42 WMLED-E3P
43 GND 44 NC
45 XCLCK1-E1P 46 NC
47 CLDAT1-E1P 48 P1V
49 CLRST1-E3N 50 GND
51 NC 52 E3V
1T
GND
2T
GND

Toshiba Tecra M10 Specifications

General

Tjunction	100 °C
Processor cache	2 MB
Processor cores	2
Processor model	T6570
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor socket	Socket 478
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.1 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel® GM45 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD
Display diagonal	14.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	4 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Discrete graphics card model	Intel® GMA 4500MHD
Maximum graphics card memory	- GB
Type	PC
Modem speed	56 Kbit/s
Power supply type	AC
Power requirements	100-240V, 50/60Hz
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
DVD+R read speed	8 x
DVD-RAM read speed	5 x
DVD+R Double Layer read speed	6 x
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows Vista Business
Sustainability certificates	ENERGY STAR
Battery capacity	5100 mAh
Number of battery cells	6
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
Product color	Silver
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
AC adapter power	75 W
AC adapter output current	5 A
AC adapter output voltage	15 V
Pointing device	Touchpad
Processor ARK ID	42841

Weight and Dimensions

Depth	245 mm
Width	336.8 mm
Weight	2440 g
Height (rear)	38.4 mm
Height (front)	36.4 mm
