Appendix C Pin Assignments Appendices
TECRA M10 Maintenance Manual (960-685) [CONFIDENTIAL] C-11
C.8 CN2300 DOCKING interface connector (140-pin)
Table C-8 DOCKING interface connector (140-pin) (1/3)
Pin No. Signal Name Pin No. Signal Name
1
DCOUT
2
DCOUT
3
DOCDT1-S3N
4
GND
5
NC
6
NC
7
NC
8
NC
9
GND
10
ZUSBDC-E3P
11
ZUSBDC-E3N
12
GND
13
GND
14
NC
15
NC
16
GND
17
NC
18
NC
19
GND
20
GND
21
GND
22
ZNDTX2-P3P
23
ZNDTX2-P3N
24
GND
25
ZNDTX1-P3P
26
ZNDTX1-P3N
27
GND
28
DVIDET-P3N
29
NC
30
NC
31
NC
32
NC
33
NC
34
NC
35
NC
36
DCOUT
37
DCOUT
38
NC
39
NC
40
NC
41
NC
42
GND
43
NC
44
GND
45
DPCONF-S5P
46
GND
47
GND
48
XNDTCK-P3N
49
XNDTCK-P3P
50
GND
51
NC
52
NC
53
GND
54
ZNDTX0-P3P
55
ZNDTX0-P3N
56
GND
57
GND
58
GND
59
GND
60
NVESCL-P5P
61
NVESDA-P5P
62
LAN-E3V
63
LINK-E3N
64
NC
65
NC
66
NC
67
ZBIDDP-EXP
68
ZBIDDN-EXN

Toshiba Tecra M10 Specifications

General

Tjunction	100 °C
Processor cache	2 MB
Processor cores	2
Processor model	T6570
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor socket	Socket 478
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.1 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel® GM45 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD
Display diagonal	14.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	4 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Discrete graphics card model	Intel® GMA 4500MHD
Maximum graphics card memory	- GB
Type	PC
Modem speed	56 Kbit/s
Power supply type	AC
Power requirements	100-240V, 50/60Hz
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
DVD+R read speed	8 x
DVD-RAM read speed	5 x
DVD+R Double Layer read speed	6 x
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows Vista Business
Sustainability certificates	ENERGY STAR
Battery capacity	5100 mAh
Number of battery cells	6
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
Product color	Silver
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
AC adapter power	75 W
AC adapter output current	5 A
AC adapter output voltage	15 V
Pointing device	Touchpad
Processor ARK ID	42841

Weight and Dimensions

Depth	245 mm
Width	336.8 mm
Weight	2440 g
Height (rear)	38.4 mm
Height (front)	36.4 mm
