Toshiba TOSVERT VF-S15 series User Manual

E6581913
68
 Command parameters
For those parameters that contain data only in the RAM and not in the EEPROM, their data return
to initial values when the power is turned off, in failure resetting, or when standard shipment settings
are set. Note that parameters without data storage in the EEPROMs will be written in the RAM
only even if the command W (writing in EEPROMs and RAM) is executed.
 Commands Note: Data is expressed in decimal notation.
C
ommunica
-
tion
Num-
ber.(HEX)
Function
Adjustment Range
Min.
Setting
Unit
Initial
Value
Write
During
O
pe
r
atio
n
EEP
ROM
FA00 Communication command 1
(RS485)
＊
1
0 to 65535 - 0 yes None
FA01 Frequency command value
(RS485)
＊
1
0 to Max. frequency
(
fh)
0.01Hz 0 yes None
FA03 Operation panel operation fre-
quency
Low-limit frequency
(
ll) to High-limit
frequency (
ul)
0.01Hz 0 yes Available
FA08 Local/Remote selection 0:Remote
1:Local
- 0 yes Available
FA10
Panel key selection
＊
3
0: Main unit
1: Communication
- 0 yes None
FA11 External communication key
data
＊
3
0 to 65535 - 0 yes None
FA13 Motor speed command (FA13) 0 to 24000min
-1
1min
-1
0 yes None
FA20 Communication command 2
(RS485)
＊
1
0 to 65535 - 0 yes None
FA26 Communication command 3 0 to 65535 - 0 yes None
FA50
Output data on the terminal
board
＊
2
0 to 255 1 0 yes None
FA51
FM analog output
＊
2
0 to 100.0
(resolution of 10 bits)
0.1% 0 yes None
FA65 Select display by communica-
tion
＊
3
0 to 2 - 1 yes Available
FA66
Numerical display data
＊
3
0-9999 1 0 yes Available
FA67
Decimal point position
＊
3
0 to 2 - 0 yes Available
FA68
LED data for unit 0
＊
3
0 to 3 - 0 yes Available
FA70 ASCII display data 1
First digit from left
＊
3
0 to 127 -
100
(’
d’)
yes Available
FA71 ASCII display data 1
Second digit from left
＊
3
0 to 255 -
65
(’
a’)
yes Available
FA72 ASCII display data 1
Third digit from left
＊
3
0 to 255 -
116
(’
t’)
yes Available
FA73 ASCII display data 1
Fourth digit from left
＊
3
0 to 127 -
65
(’
a’)
yes Available
FA74
LED data for unit1
＊
3
0 to 3 -
0
yes Available
FA75 ASCII display data 2
First digit from left
＊
3
0 to 127 -
48
(’
0’)
yes Available
FA76 ASCII display data 2
Second digit from left
＊
3
0 to 255 -
48
(’
0’)
yes Available
FA77 ASCII display data 2
Third digit from left
＊
3
0 to 255 -
48
(’
0’)
yes Available
FA78 ASCII display data 2
Fourth digit from left
＊
3
0 to 127 -
48
(’
0’)
yes Available
FA79
LED data for unit 2
＊
3
0 to 3 - 0 yes Available
FA80
Block communication mode
＊
3
0 to 1 - 0 yes Available
FA87 Reset information 0 to 255 - 0 yes None
＊
1
:Enable the communication command or communication frequency setting before setting these
parameters are set. Otherwise, the parameters will not function. See “8.1. Command by
communication” for t
he method to enable them.
＊
2
:See “8.1. Communication commands (command from the computer)” for the detail information.
＊
3
:See “8.3. Utilizing panel (LEDs and keys) by communication” for the detail information.
