E6581913
73
Appendix 3 Type and Form (FB05)
3-phase 240V class
Inverter model (capacity)
code (FB05)
Type and Form Voltage / Capacity
Data
(hex)
Data
(decimal)
VFS15-2004PM-W 3ph 200/240V 0.4kW 2 2
VFS15-2007PM-W 3ph 200/240V 0.75kW 4 4
VFS15-2015PM-W 3ph 200/240V 1.5kW 6 6
VFS15-2022PM-W 3ph 200/240V 2.2kW 7 7
VFS15-2037PM-W 3ph 200/240V 3.7/4.0kW 9 9
VFS15-2055PM-W 3ph 200/240V 5.5kW A 10
VFS15-2075PM-W 3ph 200/240V 7.5kW B 11
VFS15-2110PM-W 3ph 200/240V 11kW 6C 108
VFS15-2150PM-W 3ph 200/240V 15kW 6D 109
1-phase 240V class
Inverter model (capacity)
code (FB05)
Type and Form Voltage / Capacity
Data
(hex)
Data
(decimal)
VFS15S-2002PL-W 1ph 200/240V 0.2kW 19 25
VFS15S-2004PL-W 1ph 200/240V 0.4kW 1A 26
VFS15S-2007PL-W 1ph 200/240V 0.75kW 1C 28
VFS15S-2015PL-W 1ph 200/240V 1.5kW 1E 30
VFS15S-2022PL-W 1ph 200/240V 2.2kW 1F 31
3-phase 500V class
Inverter model (capacity)
code (FB05)
Type and Form Voltage / Capacity
Data
(hex)
Data
(decimal)
VFS15-4004PL-W 3ph 380/500V 0.4kW 22 34
VFS15-4007PL-W 3ph 380/500V 0.75kW 24 36
VFS15-4015PL-W 3ph 380/500V 1.5kW 26 38
VFS15-4022PL-W 3ph 380/500V 2.2kW 27 39
VFS15-4037PL-W 3ph 380/500V 3.7/4.0kW 29 41
VFS15-4055PL-W 3ph 380/500V 5.5kW 2A 42
VFS15-4075PL-W 3ph 380/500V 7.5kW 2B 43
VFS15-4110PL-W 3ph 380/500V 11kW 2C 44
VFS15-4150PL-W 3ph 380/500V 15kW 2D 45
