Point Operations
[Point 1]
Removal:
Put match marks on the radiator and torque converter cooler
hose.
[Point 2]
Removal•Installation:
SST 09010-20111-71 ................................. (1)
09010-23320-71................................. (2)
Removal:
Temporarily hoist up until the mount bolt completely comes out
of the hole in the frame.
[Point 3]
Removal:
Use a flat-head screwdriver for separation.
If the fitting is too tight, change the SST hook position and
adjust the engine angle for easier separation.
SST(1)
SST(2)
Engine
Section 1
1-11d
8FGCU15,18,SU20

Toyota 8FGCU25 Specifications

General

Load Capacity	5000 lbs
Lift Height	189 inches
Power Source	Internal Combustion
Fuel Type	Gasoline/LPG
Operator Type	Seated
Lift Speed (loaded/unloaded)	122 fpm
Lowering Speed (loaded/unloaded)	98 fpm / 98 fpm
Mast Height (lowered/raised)	83 inches
Weight	3, 500 kg
