REGULATOR
The regulator supplies vaporized LPG after pressure reduction to the engine while maintaining the pressure at a fixed
level.
SPECIFICATIONS
First chamber pressure kPa (psi) 24.5 to 34.3 (3.6 to 5.0)
First seat inner diameter mm (in) 3.2 (0.1)
Secondary seat inner diameter mm (in) 6.0 (0.2)
Slow system flow shut off method Solenoid valve
Drain cock Optionally available
01.book 5 ページ ２００７年２月２２日 木曜日 午後４時４６分
LPG Device for 4Y-E Engine
Section 1.3.1

Toyota 8FGCU25 Specifications

General

Load Capacity	5000 lbs
Lift Height	189 inches
Power Source	Internal Combustion
Fuel Type	Gasoline/LPG
Operator Type	Seated
Lift Speed (loaded/unloaded)	122 fpm
Lowering Speed (loaded/unloaded)	98 fpm / 98 fpm
Mast Height (lowered/raised)	83 inches
Weight	3, 500 kg
