TP-Link TL-WA1801 User Manual

5
Chapter 1
Get to Know About Your Access Point
LED Explanation
Name Status Indication
(Power)
On Power is on.
Blinking
once every
second
The system is starting up or the firmware upgrade is in progress.
Do not disconnect or power off your access point.
Blinking
twice every
second
WPS connection is in progress. This may take up to 2 minutes.
Off Power is off.
(Ethernet)
On The Ethernet port is connected to a powered-on device.
Off The Ethernet port is not connected to a powered-on device.
(2.4GHz)
On/Off
For Access Point/Multi-SSID mode:
The 2.4GHz wireless band is enabled or disabled.
For Range Extender/Client mode:
The device is connected or not connected to a 2.4GHz main
network.
(5GHz)
On/Off
For Access Point/Multi-SSID mode:
The 5GHz wireless band is enabled or disabled.
For Range Extender/Client mode:
The device is connected or not connected to a 5GHz main
network.
1. 2. 2. Back Panel

TP-Link TL-WA1801 Specifications

General

2.4 GHz	Yes
Frequency band	2.4 - 5 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	1201 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Security algorithms	SNMP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3
Service Set Identifier (SSID) features	Multiple SSIDs
Supported protocols	IPv4, IPv6
Ethernet LAN (RJ-45) ports	1
Input current	0.375 A
DC voltage range	48 V
Power over Ethernet (PoE) type supported	Passive PoE
Placement	Table
Product color	White
Antenna type	External
Antennas quantity	4
Cables included	LAN (RJ-45)
Number of products included	1 pc(s)
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Depth	145.5 mm
Width	225 mm
Height	37 mm
