Page #3 background image
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may
cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Note: The manufacturer is not responsible for any radio or tv interference caused by unauthorized
modifications to this equipment. Such modifications could void the user’s authority to operate the
equipment.
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This device and its antenna must not be co-located or operating in conjunction with
any other antenna or transmitter.
“To comply with FCC RF exposure compliance requirements, this grant is applicable to only
Mobile Configurations. The antennas used for this transmitter must be installed to provide a
separation distance of at least 20 cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.”
CE Mark Warning
This is a class B product. In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.

Other manuals for TP-Link TL-WA801ND

Questions and Answers:

TP-Link TL-WA801ND Specifications

General IconGeneral
5 GHzNo
Modulation16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
Frequency band2.4 - 2.4835 GHz
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity270M: -68dBm@10% PER\\r 130M: -68dBm@10% PER\\r 108M: -68dBm@10% PER\\r 54M: -68dBm@10% PER\\r 11M: -85dBm@8% PER\\r 6M: -88dBm@10% PER\\r 1M: -90dBm@8% PER
Ethernet LAN data rates10, 100 Mbit/s
Maximum data transfer rate300 Mbit/s
Quality of Service (QoS) supportYes
Antenna typeExternal
Antenna featuresDetachable antenna
Antennas quantity2
Antenna connector typeRP-SMA
Antenna direction typeOmni-directional
Antenna gain level (max)5 dBi
WAN connectionEthernet (RJ-45)
USB 2.0 ports quantity-
Ethernet LAN (RJ-45) ports1
Output current0.6 A
Output voltage9 V
Output power description9VDC / 0.85A
Power over Ethernet (PoE) type supportedPassive PoE
Transmit power range0 - 20 dBmW
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
PlacementTable
CertificationCE, FCC, RoHS
Security algorithms128-bit WEP, 152-bit WEP, 64-bit WEP, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Compatible operating systemsWindows 98SE, NT, 2000, XP, Vista, 7\\r MAC OS\\r NetWare\\r UNIX\\r Linux
Package depth223 mm
Package width310 mm
Package height70 mm
Package weight600 g
Weight and Dimensions IconWeight and Dimensions
Depth125 mm
Width181 mm
Height36 mm

Summary

Package Contents

Chapter 1: Introduction

Main Features

Highlights the key capabilities and specifications of the wireless access point.

Chapter 3: Quick Installation Guide

Quick Setup Process

Provides a step-by-step wizard for rapid initial configuration of the access point.

Chapter 4: Configure the Device

Logging into the Management Interface

Instructions on how to access the device's web-based configuration page.

Wireless Protected Setup (WPS)

Explains how to use WPS for quick and secure wireless network connections.

Network Configuration Settings

Allows customization of network parameters like IP address and subnet mask.

Wireless Settings

Configures basic wireless parameters such as SSID, channel, and mode.

Wireless Security Settings

Sets up encryption and authentication methods for wireless network security.

DHCP Settings

Configures the access point to act as a DHCP server for assigning IP addresses.

Appendix C: Troubleshooting

Common Troubleshooting Scenarios

Addresses common problems like password recovery and accessing the configuration page.

Appendix D: Specifications
