TP-Link TL-WA901N User Manual

20
Chapter 4
Congure the Access Point
• Received (Bytes) - Traffic in bytes received from the ETHERNET port.
• Received (Packets) - Traffic in packets received from the ETHERNET port.
• Sent (Bytes) - Traffic in bytes sent out from the ETHERNET port.
• Sent (Packets) - Traffic in packets sent out from the ETHERNET port.
• System Up Time - The length of the time since the access point was last powered on
or reset.
Click Refresh to get the latest status and settings of the access point.
4. 2. Operation Mode
If you want to change the mode of your access point after it has been first configured,
you can select the mode you want in Operation Mode.
1. Visit http://tplinkap.net, and log in using the password you created.
2. Go to Operation Mode.
3. Select the mode you want.
4. 3. Network
4. 3. 1. LAN
1. Visit http://tplinkap.net, and log in using the password you created.
2. Go to Network > LAN.
3. Configure the IP parameters of the LAN and click Save.

TP-Link TL-WA901N Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2400-2483.5 GHz
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	450 Mbit/s
Security algorithms	64-bit AES, 128-bit AES, WPA, WPA-PSK, WPA2, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	0.85 A
Output voltage	9 V
Power over Ethernet (PoE) type supported	Passive PoE
Placement	Table
Product color	White
Antenna type	External
Antennas quantity	3
Antenna direction type	Omni-directional
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Number of products included	1 pc(s)
Minimum system requirements	Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, , NetWare, UNIX or Linux , Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other , Java-enabled browser , Cable or DSL Modem , Subscription with an Internet Service Provider (for Internet access)
Package depth	223 mm
Package width	370 mm
Package height	70 mm
Package weight	660 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	133.8 mm
Width	194.8 mm
Height	36.2 mm
