TP-Link TL-WA901N User Manual

39
Chapter 4
Congure the Access Point
• Rate - The Throughput unit.
• Run Time - How long this function is running.
• Transmit - Wireless transmit rate information.
• Receive - Wireless receive rate information.
Click Start/Stop to start or stop wireless throughput monitor.
4. 5. System Tools
4. 5. 1. SNMP
Simple Network Management Protocol (SNMP) is a popular network monitoring and
management protocol.
1. Visit http://tplinkap.net, and log in using the password you created.
1. Go to System Tools > SNMP.
• SNMP Agent - Select the radio button before Enable will enable this function if you
want to have remote control through SNMPv1/v2 agent with MIB-II. Select the radio
button before Disable will disable this function. The default setting is Disable.
• SysContact - The textual identification of the contact person for this managed node.
• SysName - An administratively-assigned name for this managed node.
• SysLocation - The physical location of this node.
Note:
If you are not familiar with the setting items on this page, it’s strongly recommended to keep the provided default values;
otherwise it may result in lower wireless network performance.
• Get Community - Enter the community name that allows Read-Only access to the
Device’s SNMP information. The community name can be considered a group
password. The default setting is “public”.
• Get Source - Get source defines the IP address or subnet for management systems
that can read information from this ‘get’ community device.

TP-Link TL-WA901N Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2400-2483.5 GHz
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	450 Mbit/s
Security algorithms	64-bit AES, 128-bit AES, WPA, WPA-PSK, WPA2, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	0.85 A
Output voltage	9 V
Power over Ethernet (PoE) type supported	Passive PoE
Placement	Table
Product color	White
Antenna type	External
Antennas quantity	3
Antenna direction type	Omni-directional
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Number of products included	1 pc(s)
Minimum system requirements	Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, , NetWare, UNIX or Linux , Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other , Java-enabled browser , Cable or DSL Modem , Subscription with an Internet Service Provider (for Internet access)
Package depth	223 mm
Package width	370 mm
Package height	70 mm
Package weight	660 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	133.8 mm
Width	194.8 mm
Height	36.2 mm
