TP-Link TL-WA901N User Manual

23
Chapter 4
Congure the Access Point
4. 4. Wireless
4. 4. 1. Wireless Settings
1. Visit http://tplinkap.net, and log in using the password you created.
2. Go to Wireless > Wireless Settings.
3. Four operation modes are supported here, including Access Point, Multi-SSID, Client, and
Range Extender.
Access Point Mode
• Wireless Network Name - Identifies your wireless network name. Create a name up to
32 characters and make sure all wireless points in the wireless network with the same
SSID. The default SSID is TP-LINK_AP_XXXX (XXXX indicates the last unique four
characters of each device’s MAC address). This value is case-sensitive. For example,
TEST is NOT the same as test.
• Channel - Determines the operating frequency to be used. It is not necessary to
change the wireless channel unless you notice interference problems with another
nearby access point.
• Mode - Select the desired wireless mode. The options are:
• 11b only - Only 802.11b wireless stations can connect to the device.
• 11g only - Only 802.11g wireless stations can connect to the device.
• 11n only - Only 802.11n wireless stations can connect to the device.
• 11bg mixed - Both 802.11b and 802.11g wireless stations can connect to the
device.
• 11bgn mixed - All 802.11b, 802.11g and 802.11n wireless stations can connect
to the device.
• Channel Width - Determines the channel width to be used. It is unnecessary to change
the default value unless required.

TP-Link TL-WA901N Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2400-2483.5 GHz
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	450 Mbit/s
Security algorithms	64-bit AES, 128-bit AES, WPA, WPA-PSK, WPA2, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	0.85 A
Output voltage	9 V
Power over Ethernet (PoE) type supported	Passive PoE
Placement	Table
Product color	White
Antenna type	External
Antennas quantity	3
Antenna direction type	Omni-directional
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Number of products included	1 pc(s)
Minimum system requirements	Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, , NetWare, UNIX or Linux , Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other , Java-enabled browser , Cable or DSL Modem , Subscription with an Internet Service Provider (for Internet access)
Package depth	223 mm
Package width	370 mm
Package height	70 mm
Package weight	660 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	133.8 mm
Width	194.8 mm
Height	36.2 mm
