TP-Link TL-WDR4300 User Manual

TL-WDR4300 N750 Wireless Dual Band Gigabit Router
- 97 -
Click the Enable All button to enable all the entries.
Click the Disable All button to disable all the entries.
Click the Delete All button to delete all the entries.
Click the Previous button to view the information in the previous screen, click the Next button to
view the information in the next screen.
4.15.2 System Routing Table
Choose menu “Advanced Routing s System Routing Table”, and then you can view the
System Routing Table in the next screen (shown in Figure 4-94). System routing table views all of
the valid route entries in use. The Destination IP address, Subnet Mask, Gateway, and Interface
will be displayed for each entry.
Figure 4-94 System Routing Table
Ü Destination Network - The Destination Network is the address of the network or host to
which the static route is assigned.
Ü Subnet Mask - The Subnet Mask determines which portion of an IP address is the network
portion, and which portion is the host portion.
Ü Gateway - This is the IP address of the gateway device that allows for contact between the
Router and the network or host.
Ü Interface - This interface tells you either the Destination IP Address is on the LAN & WLAN
(internal wired and wireless networks), or on the WAN (Internet).
4.16 Bandwidth Control
Figure 4-95 Bandwidth Control

TP-Link TL-WDR4300 Specifications

General

Color	black
Frequency Band	other
QoS Traffic Prioritization	yes
Ethernet Standard	10/100/1000
Wireless Standard	n
Gigabit Ethernet Speed	yes
Antennas	3
Parental Control	yes
Firewall	spi
Data Encryption	yes
Encryption Type	wpa2-psk, wep, wpa, wpa2, wpa-psk
Security Features	wps (wi-fi protected setup)
Ports	usb
WAN Ports	1
System Requirements	pc: windows 98 se, nt, 2000, xp, vista or 7; mac os; netware; unix; linux

Weight and Dimensions

Height	9.6 inches
Width	6.4 inches
