TL-WDR4300 N750 Wireless Dual Band Gigabit Router
- 114 -
Ü Save Log - Click to save all the logs in a txt file.
Ü Mail Log - Click to send an email of current logs manually according to the address and
validation information set in Mail Settings.
Ü Clear Log - All the logs will be deleted from the Router permanently, not just from the page.
Click the Next button to go to the next page, or click the Previous button to return to the previous
page.
4.19.9 Statistics
Choose menu “System Tools
Statistics”, and then you can view the statistics of the Router,
including total traffic and current traffic of the last Packets Statistic Interval.
Figure 4-119 Statistics
Ü Current Statistics Status - Enable or Disable. The default value is disabled. To enable it,
click the Enable button. If it is disabled, the function of DoS protection in Security settings will
be disabled.
Ü Packets Statistics Interval
5-60 - The default value is 10. Select a value between 5 and
60 seconds in the drop-down list. The Packets Statistic interval indicates the time section of
the packets statistic.
Ü Sorted Rules - Choose how the displayed statistics are sorted.
Select the Auto-refresh checkbox to refresh automatically.
Click the Refresh button to refresh immediately.
Click Reset All to reset the values of all the entries to zero.
Click Delete All to delete all entries in the table.
