TL-WDR4300 N750 Wireless Dual Band Gigabit Router
- 99 -
Ü Egress bandwidth - This field displays the max and mix upload bandwidth through the
Internet port, the default is 0.
Ü Ingress bandwidth - This field displays the max and mix download bandwidth through the
Internet port, the default is 0.
Ü Enable - This displays the status of the rule.
Ü Modify - Click Modify to edit the rule. Click Delete to delete the rule.
To add/modify a Bandwidth Control rule, follow the steps below.
1. Click Add New… shown in Figure 4-97, you will see a new screen shown in Figure 4-98.
2. Enter the information like the screen shown below.
Figure 4-98 Bandwidth Control Rule Settings
3. Click the Save button.
4.17 IP & MAC Binding Setting
Figure 4-99 the IP & MAC Binding menu
There are two submenus under the IP &MAC Binding menu (shown in Figure 4-99): Binding
Settings and ARP List. Click any of them, and you will be able to scan or configure the
corresponding function. The detailed explanations for each submenu are provided below.
4.17.1 Binding Settings
This page displays the IP & MAC Binding Setting table; you can operate it in accord with your
desire (shown in
Figure 4-100).
