TL-WDR4300 N750 Wireless Dual Band Gigabit Router
- 49 -
Ü BSSID(to be bridged) - The BSSID of the AP your Router is going to connect to as a
client. You can also use the search function to select the BSSID to join.
Ü Survey - Click this button, you can search the AP which runs in the current channel.
Ü Key type - This option should be chosen according to the AP's security configuration. It
is recommended that the security type is the same as your AP's security type
Ü WEP Index - This option should be chosen if the key type is WEP(ASCII) or
WEP(HEX).It indicates the index of the WEP key.
Ü Auth Type - This option should be chosen if the key type is WEP(ASCII) or
WEP(HEX).It indicates the authorization type of the Root AP.
Ü Password - If the AP your Router is going to connect needs password, you need to fill
the password in this blank.
4.7.2 WPS
Choose menu “Wireless 5GHz
WPS”, you can the screen as shown in Figure 4-31. This
section will guide you to add a new wireless device to an existing network quickly by WPS (Wi-Fi
Protected Setup) function.
Figure 4-31 WPS
Ü WPS Status - Enable or disable the WPS function here.
Ü Current PIN - The current value of the Router's PIN is displayed here. The default PIN of the
Router can be found in the label or User Guide.
Ü Restore PIN - Restore the PIN of the Router to its default.
Ü Gen New PIN - Click this button, and then you can get a new random value for the Router's
PIN. You can ensure the network security by generating a new PIN.
Ü Add device - You can add a new device to the existing network manually by clicking this
button.
