Trane Tracer AH540 User Manual

Appendix
106 CNT-SVX05B-EN
Input sensor tables
Table 73. Trane zone sensor hard-wired setpoint thumbwheel
Setpoint Resistance
50°F (10.0ºC) 889.4 Ω
58°F (14.4ºC) 733.6 Ω
66°F (18.9ºC) 577.9 Ω
70°F (21.1ºC) 500.0 Ω
74°F (23.3ºC) 422.1 Ω
78°F (25.6ºC) 344.2 Ω
82°F (27.8ºC) 266.4 Ω
86°F (30.0ºC) 188.5 Ω
90°F (32.2ºC) 110.6 Ω
Table 74. Hard-wired 10 kΩ thermistor values
Temperature Resistance (kΩ)
Temperature
(continued)
Resistance (kΩ)
(continued)
0ºF (17.8ºC) 87.5 77°F (25.0ºC) 10.0
5°F (-15.0ºC) 74.6 80°F (26.7ºC) 9.3
10°F (-12.2ºC) 63.8 85°F (29.4ºC) 8.2
15°F (9.4ºC) 54.6 90°F (32.2ºC) 7.3
20°F (6.7ºC) 46.9 95°F (35.0ºC) 6.5
25°F (3.9ºC) 40.4 100°F (37.8ºC) 5.8
30°F (-1.1ºC) 34.8 105°F (40.6ºC) 5.2
35°F (1.7ºC) 30.2 110°F (43.3ºC) 4.7
40°F (4.4ºC) 26.2 115°F (46.1ºC) 4.2
45°F (7.2ºC) 22.8 120°F (48.9ºC) 3.8
50°F (10.0ºC) 20.0 125°F (51.7ºC) 3.4
55°F (12.8ºC) 17.5 130°F (54.4ºC) 3.1
60°F (15.6ºC) 15.3 135°F (57.2ºC) 2.8
65°F (18.3ºC) 13.5 140°F (60.0ºC) 2.5
70°F (21.1ºC) 11.9 145°F (62.8ºC) 2.3
75°F (23.9ºC) 10.5 150°F (65.6ºC) 2.1
