Tyco Electronics Galaxy SC Controller J85501F-1
Issue 13 February 2001 T1.317 Objects and Attributes Appendix B - 15
Table B-10: Alarm And Events Objects and Attribute, continued
THRESHOLD VOLTAGE RANGES (default:min-max)
IDE DEFAULT DESCRIPTION FLOAT BOOST
Notify Destination DST TEXT X X X “”,P1,P2,P3,P4
BDA1 Battery On Discharge 23-28:25V or 46-55:51V 23-28:25V or 46-55:51V
HVA1 High Voltage 24.75-29.75:26.8V or 50-60:53.6V25.75-
31.75:26.8V or 52-60:53.6V
HFV1 High Float Voltage 24.75-29.75:26.5V or 50-60:53V25.75-
31.75:26.5V or 52-60:53V
Related Commands
ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE
User Defined Events UDE
Identifier IDE TEXT 6 char (default: Unnnn (nnnn=1-
1500)
Description DES TEXT X X X 30 char
Alarm State AST NUMBER 0:inactive 1:active
Severity SEV TEXT X X X CRIT, MAJ, MIN, WRN, RO
Program Line PRG TEXT X X X 60 char
Minimum Duration DUR NUMBER X X X > 0 seconds
Latched LAT NUMBER X X X 0:no 1:yes
LED LED TEXT X X X “”,BATT, BD, DIST, RECT, AC,
RM, or CTLR
Contact Closure ACC TEXT X X X “”,ACF,MJF,MNF,RFA,VLV,HV,
BD,CTLR,UR1, or UR2
Notify Delay DLY NUMBER X X X 0-540 seconds
Notify On Occur NOO NUMBER X X X 0:no 1:yes
Notify On Retire NOR NUMBER X X X 0:no 1:yes
NAG On Occur NAG NUMBER X X X 0:no 1:yes
Notify Destination DST TEXT X X X “”,P1,P2,P3,P4
Timer Events TME
Identifier IDE TEXT 6 char (default: Tnn (nn=1-32)
Description DES TEXT X X X 30 char
State STT NUMBER 0:inactive 1:active
Date DAT DATE X X X date (00/00/0000 daily)
Time TIM TIME X X X time (default: 11:59am)
Duration DUR NUMBER X X X 1 to 1440 minutes (0:forever)
Maintenance Reminder MRM
Identifier IDE TEXT MRnn (nn=1 to 12)
Description DES TEXT X X X Maintenance Reminder nn
Alarm State AST NUMBER 0:inactive 1:active
Severity SEV TEXT WRN (not changeable)
Notify On Occur NOO NUMBER X X X 0:no 1:yes
Notify On Retire NOR NUMBER X X X 0:no 1:yes
NAG On Occur NAG NUMBER X X X 0:no 1:yes
Notify Destination DST TEXT X X X “”,P1,P2,P3,P4
Notification Date DAT DATE X X X 01/01/1992
Notification TIME TIM TIME X X X 12:00AM
Text TXT TEXT X X X 60 char
Connected Equipment Alarm CEA
Identifier IDE TEXT CEA1, CEA2, CEA3, and CEA4
Description DES TEXT X X X Connected Equip Alarm n
Alarm State AST NUMBER 0:inactive 1:active
Severity SEV TEXT X X X CRIT, MAJ, MIN, WRN, RO
Notify Delay DLY NUMBER X X X 0-540 seconds
Notify On Occur NOO NUMBER X X X 0:no 1:yes
Notify On Retire NOR NUMBER X X X 0:no 1:yes
NAG On Occur NAG NUMBER X X X 0:no 1:yes
Notify Destination DST TEXT X X X “”,P1,P2,P3,P4
