Ubee DDW36C User Manual

Ubee Interactive Using the DHCP Option
Ubee DDW36C Advanced Wireless Gateway MSO Operations Guide • October 2015 34
5.2 Using the DHCP Option
Use the DHCP option to configure dynamic host configuration protocol-specific behavior
on the device.
Steps
To configure DHCP settings:
1. Click Basic from the main menu.
2. Click DHCP from the left side menu. Field descriptions are listed below the screen
example.
IPv6 DNS Servers Lists the IPv6DNS servers available on the network.
Release WAN Lease Releases the WAN public IP address when clicked.
Renew WAN Lease Renews the WAN IP address when clicked.
WAN Connection Type Selects the WAN connection type. For each type, different data
entry is required, as explained below:
 DHCP: The WAN interface is set to a DHCP client, and
the IP address is assigned by the service provider’s DHCP
server.
 Static IP: For Static IP, you must manually enter the IP
address for the WAN interface.
 PPTP (dhcp): For Point to Point Tunneling Protocol
(PPTP), you must enter a username, password, and the
PPTP server’s IP address.
 PPTP (static):
 L2TP (dhcp):
 L2TP (static):
Host Name Defines the host name for the router. This may be required by
some service providers.
Domain Name Defines the domain name for the router. This may be required
by some service providers.
IPv4 MTU Size Defines the maximum transmission unit (MTU) size. MTU
defines the largest size of the packet or frame that the device
can transfer (256-1500). If this is not given by your service
provider, use 0 for the default.
Apply Saves changes.
Label Description
