Ubee Interactive
Ubee DDW36C Advanced Wireless Gateway Subscriber User Guide • October 2015 72
8.4 Using the Local Log Option
The Local Log option displays Parental Control event log reporting.
To view the parental control local log:
1. Click the Parental Control link from the top of the screen.
2. Click Local Log from the left side of the screen. The Local Log fields are explained
following this screen example.
Label Description
Add New Policy Adds a new policy. Enter a policy name and click the Add New
Policy button.
Time Access Policy List Lists the existing policies in a drop-down list.
Enabled Activates a policy. Select the policy from the drop-down list
and check Enabled.
Remove Deletes a policy. Select the policy from the drop-down list and
click Remove.
Days to Block Selects the days to block Internet access.
Time to Block:
All Day or a specific time frame
Defines the time to block.
To block all day, check All Day to eliminate all access
during the days selected.
To block a specific time frame for the days selected, enter
the Start time and the End time. Select AM or PM for
each.
Ports to Block Defines a port range to block if the Enabled box is checked.
Port Start: Enter the starting port number to be blocked.
Port End: Enter ending port number to be blocked.
Protocol: Select the protocol type. Options are UDP, TCP,
or Both.
Apply Saves all changes when clicked.
