Ubee Interactive Using the DHCPv6 Option
Ubee DDW36C Advanced Wireless Gateway MSO Operations Guide • October 2015 36
5.3 Using the DHCPv6 Option
Use the DHCPv6 option to configure IPv6 host IP addresses, IPv6 prefixes, and various
configuration data required to operate in an IPv6 network.
To configure DHCPv6 settings:
1. Click Basic from the main menu.
2. Click DHCPv6 from the left side menu. Field descriptions are listed below the screen
example.
DHCP Clients Lists all DHCP clients currently connected to the device, either
via an Ethernet connection, or via a wireless connection. Each
client is listed with the following information:
MAC Address / IP Address / Subnet Mask
Duration: Duration displays the accumulated time since
the client acquired the IP address.
Expires: Expires is the time until the IP expires and must
be recycled. If the IP address is reserved to a certain
host, it shows STATIC IP ADDRESS.
Select: Reserves the current private IP address to be
assigned to this host statically when selected.
Current System Time Displays the current system time.
Force Available Activates a selected rule in the DHCP Clients list and assigns
IP addresses. Note: The Select button must be activated in the
DHCP list.
Label Description
