GEAR CHANGE SELECTOR PARTS
Clutch push rod
Selector spring stud
Clutch lever
Bolt
Clutch cable securing plate
Gear selection lever
Selector shaft assembly
Spring
D12 safety ring
Washer
Bolt
Washer
Drum control head
Gear selection spring
Special bolt
Gear lever assy.
6M100x25 bolt
D6 washer
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
62
ASSEMBLING THE ENGINE
AND ADJUSTMENTS
WORKSHOP MANUAL
