C LUTCH COVER PARTS
Clutch cover assy.
Clutch cover – crankcase gasket
Oil lter cover
O-ring
Oil lter cartridge spring
Oil lter cartridge
M5x14 bolt
Water pump cover
O-ring
Complete drive shaft
Water pump oil seal
Clamp
M6x35 bolt
Oil seal
Pump-cylinder head pipe
Oil pressure sensor
Washer
Water pump shaft assy.
20x30x5 oil seal
Water pump gear
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
74
