UPO2000CS series User Manua
85
Timing Accuracy ≤±(50+ 2×Service Life)ppm
Delay
Pre-trigger（Negative Delay）：≥1 Screen Width
Post-trigger（Positive Delay）：1 s~50 s
Timebase
YT、XY、ROLL
Waveform Capture
Rate
50,000 wfms/s
Sampling
Sampling Mode Teal-time Sampling
Real-time
Sampling Rate
1GS/s(Single Channel)，500MS/s(Dual Channel)，250MS/s(Quad Channel)
1GS/s(Single Channel)，500MS/s(Dual Channel)(UPO2202CS)
Acquisition Mode Sampling, peak detection, high resolution, envelope, and average
Average Value
After all channels reach N times sampling, N times in 2, 4, 8, 16, 32, 64, 128, 256, 512, 1024, 2048,
4096, and 8192
Waveform
Interpolation
sin(x)/x
Storage Depth Auto, 28kpts, 280kpts, 2.8Mpts, 28Mpts
Trigger
Trigger Level
Range
Internal：Center of the screen ± 8 grids
External：± 0.8V
Trigger Mode Automatic, normal, single
Trigger Holdoff
Range
100ns~10s
High Frequency
Suppression
50kHz
Low Frequency
Suppression
5kHz
Noise Suppression
Reduce Noise Waveform（10 mV/div～20 V/div，DC coupling trigger sensitivity reduced by 2 times）
Trigger Sensitivity ≤1div
Edge Trigger
Edge Type Rising, falling, any
Pulse Width Trigger
Pulse Condition
>、<、=
Polarity Positive, negative pulse width
Pulse Width
Range
4ns ~ 10s
Under-range Pulse Trigger
