UNI-T UTL8500X Series User Manual

Programable DC Electronic Load User Manual
64
Table 6-2 Description of Parameter Setting (UTL8512S)
Parameter setting Setting range Description
Run time 0~99999s Set the time for scheduled unload
Delay on 0~9999s Set the start time of delay
Short time 0.1~99999ms Set the time for short circuit test
V limit 0~150V
Set the voltage value of over-voltage
protection
I limit 0~30A
Set the current value of over-current
protection
P limit 0~300W
Set the power value of over-power
protection
V on 0~150V
Set the load voltage at the beginning of
each run
V off 0~150V
Set the low voltage to automatically
end loading
V trigger 0~150V
Set the self-start voltage of the list
mode
OVP ON/OFF
Set whether to enable the overvoltage
protection function
Digit filt LV1/LV2/LV3/LV4 Set the level of digital filter
Trig select Trig/On/Off
Set the role of external trigger signal
input (function multiplexing)
Ripple Fast-V/Fast-I/Medium/Off
Set the ripple sampling method, set the
hardware high-speed sampling voltage
ripple/current ripple
VPP limit 0~15V
Set the protection value for excessive
ripple voltage
I rise 0.001~30A/mS Set the current rising slope under load
I fall 0.001~30A/mS Set the current fall slope under load
V rise 0.010~15V/mS Set the voltage rise slope under load
V fall 0.010~15V/mS Set the voltage fall slope under load
Power type Auto/CV/CC Set the type of power supply under test
6.2.1 Run Time
If users set the single load time of the electronic load, no matter what mode it is running in,
the load will automatically stop loading after the set timing is reached. When this function
is not needed, set the parameter to 0.
