86 Entrance telephone
System appointment function
You can use your handset to enter a single appointment for the next 24 hours
or an appointment that recurs on a daily basis.
When the appointment is due, your handset rings for approx. 20 seconds to
remind you of your appointment. The entered appointment appears on the
display. This appointment call is deleted when you confirm it. Alternatively it is
deleted automatically after it has been repeated 5 times at one-minute
intervals.
This function can also be called directly by entering the code  page 39.
Saving an appointment
Press and hold down the Talk key.
Open the system menu.
s t w Select the menu item and confirm.
s t w Select the menu item and confirm.
o Enter the required time.
Note the required data format: Appointment at (HHMM); HH = two-digit hour
setting mm = minutes, two digits Example: 0905 for 9.05 (= 9.05 a.m.) or 1430
for 14.30 (= 2.30 p.m.).
Either:
s t w Select the menu item.
Or:
s t w Select the menu item and confirm.
then:
Save the settings.
Press the End call key to end the operation.
Deleting/checking entered appointments
Press and hold down the Talk key.
Open the system menu.
s t w Select the menu item and confirm.
s t w Select the menu item and confirm.
Open the additional menu.
Either:
s t w Select the menu item and confirm.
Or:
s t w Select the menu item and confirm.
a Press the End call key to end the operation.
Menu
Service?
*
46=Timed reminder on?
Remind at (HHMM):
One time only??
Daily?
Save
Menu
Service?
#46=Timed reminder off?
Reminder at ... ...
Mnu
Delete?
End?
