7-2
Status / Job Cancel
Checking Job Status
Check the status of jobs being processed or waiting to be printed.
Available Status Screens
The processing and waiting statuses of jobs are displayed as a list on the Message Display in four different screens
- Print Job, Send Job, Store Job, and Scheduled Job. The following job statuses are available.
Print Job Status Screen
1 Press the Status/Job Cancel key. The Status menu
appears.
2 Press the  or  key to select [Print Job Status].
3 Press the OK key. Print Job Status appears. Press the 
or  key to check the print queue.
Screen Job statuses to be displayed
Print Job • Copy
• Printer
• FAX reception
• Document Box
• E-mail reception
• Job Report /List
• Printing data from removable memory
Send Job • FAX transmission
• PC (SMB/FTP) transmission
•E-mail
• Application
• Multiple destination
• Sending Job FAX using Delayed
transmission
Store Job • Scan
•FAX
• Printer
Scheduled Job • FAX
Status: a b
*********************
2 Send Job Status
3 Store Job Status
[ Pause ]
1 Print Job Status
Print Job Status: a b
0008 Copy
r
0009 maury’s data
0010
W aaaa
[ Pause ] [ Menu ]
123
4
