103
12.5 PROCESSING CYLINDER DOOR
Lifting the handle over the taper and shifting it to the right release the
processing cylinder door. The door can now be opened.
Closing the door and pressing the handle over the taper down, thereby
preventing it from opening automatically, close the processing cylinder door.
12.6 OUTLET HOLE COVER
Loosening (in counter-clockwise direction) the locking screw opens the ice
cream outlet hole cover and turning the whole fully (in clockwise direction)
towards the stop, where the locking screw is tightened again (in clockwise
direction).
LOCKING SCREW
