4. Installing the Equipment: Base Stand (Optional)
62 vatech A9 (Model:PHT-30CSS) Installation Manual
4.6 Removing the Transportation Safety Bolts
1. Lift the Vertical Frame Unit Cover, as shown in the figure.
2. Remove two Safety Bolts (see important) along with their tags.
Required Tool Allen Wrench 6 mm / 0.24”
Avoid damaging the cables when you are removing
the safety bolts.
the Safety Bolts are located inside the Vertical
Frame Unite, as indicated in the image below.
To Next Page
