4
.
Installi
ng the Equipment: Base Stand (O
ptional)
64
vatech A9
(Model:PHT
-
30CSS
)
Installation Manual
4.7
Leveling the Equi
pment
Required T
ool
T
-
shaped Hex
Wench
8 mm /
0.3”
Spirit
Level
N/A
Ensure to place t
he Spirit Level on the in
dicated
locations
in th
is manual for an accur
ate reading.
1.
Prepare a Spirit
Level.
2.
T
urn
the Rot
ating Unit clockwise
so
that
the
X-
r
ay tube head fac
es the front.
3.
T
urn all
nine
screws i
n marked locat
ions
clockwise.
73
75
