4.15 Haldex coupling: Changing oil
Note
♦
On vehicles with Haldex coupling the drain plugs and sealing
plugs of both systems are often interchanged, due to the in‐
tegrated housing construction of Haldex coupling and final
drive. Caution must be exercised during maintenance and
servicing, as incorrect fitting can cause the Haldex coupling
and the final drive to fail.
♦
The Haldex coupling and the final drive are one system with
separate oil systems.
♦
-1- plug for Haldex oil filler hole
♦
-2- drain plug for Haldex oil
♦
-3- plug for gear oil filler hole
♦
-4- drain plug for gear oil
Further information on arrangement of plugs ⇒ TPI 2017008
Special tools and workshop equipment required
♦ Torque wrench -V.A.G 1331-
♦ Used oil collection and extraction unit -VAS 6622-
♦ Oil spill cloth -VAS 6204/1-
Golf 2013 ➤
Maintenance - Edition 10.2012
