Volvo Penta IPS 400 User Manual

Technical Data
Engine
General information
Volvo Penta IPS system designation ....................... D4 - See table below D6- See table below
Engine model/after market designation ................... See table below See table below
Crankshaft power kW (hp)* ..................................... See table below See table below
Propellershaft power kW (hp)* ................................. See table below See table below
Idling speed ............................................................. 700 rpm 600 rpm
Swept volume .......................................................... 3.7 liter (1.0 US gals) 5.5 liter (1.5 US gals)
Injection sequence ................................................... 1-3-4-2 1-5-3-6-2-4
Direction of rotation (seen from front) ...................... Clockwise Clockwise
Max. forwards inclination ......................................... 10° 10°
Max. rearwards inclination in operation ................... 20° 20°
Max. sideways inclination in operation ..................... 30° 30°
Oil pressure, hot engine
Idling ................................................................... 1.25 bar (18.1 psi) 1.25 bar (18.1 psi)
Full speed ........................................................... 4.5 bars (65 psi) 4.5 bars (65 psi)
Compressor
Oil volume ................................................................ 0.1 liter (0.2 US pint) 0.1 liter (0.2 US pint)
Oil grade. ................................................................. VP, part no. 1141641-9 VP, part no. 1141641-9
Cooling system
Thermostats open/fully open ................................... 82°C/92°C 82°C/92°C
Fresh water system volume, app. ............................ 13 liter (3.4 US gals) 16.5 liter (4.4 US gals)
Electrical system
System voltage ........................................................ 12V 12V/24 V
Starter motor battery, capacity ................................ 2 x 88Ah 800cca 2 x 88Ah 800cca
Alternator, rated power, max .................................... 14V/115A 14V/115A, 28V/80A
Starter motor, rated power ....................................... 12V/3.6kW 12V/3.6kW, 24V/5kW
Lubrication system
Oil volume, (incl. oil filter) ......................................... 12.5 (3.3 US gals) 20 liter (4.4 US gals)
Oil volume, oil filter .................................................. 1.6 (0.4 US gals) 1.6 liter (0.4 US gals)
Oil volume between min. and max. markings .......... 1.5 (0.4 US gals 3.5 liter (0.9 US gals)
Oil grade .................................................................. See table on next page
Viscosity .................................................................. SAE 15W/40 (See table on next page)
* According to ISO 8665
Volvo Penta IPS
system designation
Engine model /
aftermarket designation
Crankshaft power
kW (hp)
Propellershaft power
kW (hp)
IPS 350 D4-260 D-B 191 (260) 182 (248)
IPS 400 D4-300 D-A 221 (300) 212 (289)
IPS 400 D6-310 D-B 228 (310) 217 (295)
IPS 450 D6-330 D-B 243 (330) 231 (314)
IPS 500 D6-370 D-B 272 (370) 259 (352)
IPS 600 D6-435 D-A 320 (435) 307 (418)
111

Volvo Penta IPS 400 Specifications

General

Brand	Volvo Penta
Model	IPS 400
Category	Engine
Language	English
