Wacker Neuson DT10 User Manual

BA DT10 en - Edition 1.5 * dt10b610.fm 6-7
Technical data
6.16 Dimensions of model DT10 with front tip skip for lightweight material (optional)
1357 700
830
180
790
1280
265
172
1
4
°
7
0
°
1950
812
460
15
466
1823 393
2670
408 875 540
Fig. 97: Vehicle dimensions (model DT10 with front tip skip for lightweight material)
Main data
Model DT10
Payload
1000 kg
Dead weight incl. skip and loader unit
705 kg
Length
1823 mm
Width
790 mm
Height
1445 mm
Foothold projection
393 mm
Track width
180 mm
Chain length
875 mm
Front skip projection
408 mm
Skip load height (front edge)
812 mm
Skip length
1357 mm
Skip width
700 mm
Skip depth
466 mm
Scraping depth
15 mm
