Wacker Neuson DT10 User Manual

6-10 BA DT10 en - Edition 1.5 * * dt10b610.fm
Technical data
6.19 Dimensions model DT10 with front skip (option)
806
180
790
1280
265
3931882
467 875 540
295554
1200
1430
5
6
°
1
4
°
Fig. 100: Vehicle dimensions (model DT10 with front skip)
Main data
Model DT10
Payload
1000 kg
Dead weight incl. skip
590 kg
Length
1882 mm
Width
806 mm
Height
1280 mm
Foothold projection
393 mm
Track width
180 mm
Chain length
875 mm
Front skip projection
467 mm
Skip load height (front edge)
850 mm
Skip length
1200 mm
Skip width
800 mm
Skip depth
295 mm
