Wacker Neuson DT10 User Manual

BA DT10 en - Edition 1.5 * dt10b610.fm 6-11
Technical data
6.20 Dimensions for model DT10 with swivel -tip skip (option)
875
546
540
393
1960
172
265
1280
1301
1
4
°
8
5
°
650
1045
2112
570
1427
730
180
790
782
337
487
Fig. 101: Vehicle dimensions (model DT10 with swivel tip skip)
Main data
Model DT10
Payload
1000 kg
Dead weight incl. swivel tip skip
775 kg
Length
1960 mm
Width
790 mm
Height
1280 mm
Foothold projection
393 mm
Track width
180 mm
Chain length
875 mm
Front skip projection
546 mm
Skip load height (front edge)
1045 mm
Skip length
1427 mm
Skip width
730 mm
Skip depth
570 mm
